Intel Xeon 5000/5100 Dual-Core CPUs
Dell PowerEdge 2900 Intel Xeon 5000/5100 Processors
Released in mid to late 2006, the Intel Xeon dual-core 5000 and 5100 series processors (code named Dempsey and Woodcrest, respectively) are designed for high-performance dual-processor server and workstation applications. Based on the Intel NetBurst microarchitecture and Hyper-Threading Technology (HT Technology), they are scalable to two processors, providing exceptional performance for applications running on advanced operating systems such as Windows XP, Windows Server 2003, Windows Server 2008, Linux, and UNIX.
The dual-core Intel Xeon 5000 and 5100 series also include Hyper-Threading Technology (HT Technology) resulting in four logical processors per processor. This feature allows multi-threaded applications to execute more than one thread per physical processor core, increasing the throughput of applications and enabling improved scaling for server and workstation workloads.
The Dell PowerEdge 2900 will take up to two (2) processors. When adding a second processor to an existing server, the Intel sSpec code must match the first CPU.
Unless otherwise noted, processors have been tested and removed from working servers and are backed by our 90-day parts replacement warranty. Heatsinks are sold separately.
Click a processor below for more information, availability and pricing.
| Intel Xeon 5000 Series Processors (Dempsey) | ||||||
| Model number | Intel sSpec number |
Frequency (GHz) |
L2 (per core) | Front Side Bus (FSB) | Voltage | TDP |
|---|---|---|---|---|---|---|
| Dual Core | ||||||
| Xeon 5020 |
|
2.5 GHz | 2 x 2MB | 667 MHz | 1.075–1.35 V | 95 W |
| Xeon 5030 | 2.67 GHz | 2 x 2MB | 667 MHz | 1.075–1.35 V | 95 W | |
| Xeon 5040 |
|
2.83 GHz | 2 x 2MB | 667 MHz | 1.075–1.35 V | 95 W |
| Xeon 5050 | 3.0 GHz | 2 x 2MB | 667 MHz | 1.075–1.35 V | 95 W | |
| Xeon 5060 | 3.2 GHz | 2 x 2MB | 1066 MHz | 1.075–1.35 V | 130 W | |
| Xeon 5070 |
|
3.46 GHz | 2 x 2MB | 1066 MHz | 1.075–1.35 V | 130 W |
| Xeon 5080 | 3.73 GHz | 2 x 2MB | 1066 MHz | 1.075–1.35 V | 130 W | |
| Dual Core, medium power | ||||||
| Xeon X5063 | 3.2 GHz | 2 x 2MB | 1066 MHz | 1.075–1.35 V | 95 W | |
| Intel Xeon 5100 Series Processors (Woodcrest) | ||||||
| Model number | Intel sSpec number |
Frequency (GHz) |
L2
| Front Side Bus (FSB) | Voltage | TDP |
|---|---|---|---|---|---|---|
| Dual Core | ||||||
| Xeon 5110 | 1.6 GHz | 4MB | 1066 MHz | 1.0–1.5 V | 65 W | |
| SLABR | ||||||
| SLAGE | ||||||
| Xeon 5120 | 1.87 GHz | 4MB | 1066 MHz | 1.0–1.5 V | 65 W | |
| SLABQ | ||||||
| SLAGD | ||||||
| Xeon 5130 | 2.0 GHz | 4MB | 1333 MHz | 1.0–1.5 V | 65 W | |
| SLABP | ||||||
| SLAGC | ||||||
| Xeon 5140 | 2.33 GHz | 4MB | 1333 MHz | 1.0–1.5 V | 65 W | |
| SLABN | ||||||
| SLAGB | ||||||
| Xeon 5150 | 2.67 GHz | 4MB | 1333 MHz | 1.0–1.5 V | 65 W | |
| SLABM | ||||||
| SLAGA | ||||||
| Xeon 5160 | 3.0 GHz | 4MB | 1333 MHz | 1.0–1.5 V | 80 W | |
| SLABS | ||||||
| SLAG9 | ||||||
| Dual Core, low voltage |
||||||
| Xeon LV 5113 | SLAG7 | 1.6 GHz | 4MB | 800 MHz | 1.0–1.5 V | 40 W |
| Xeon LV 5128 | SL9XA | 1.87 GHz | 4MB | 1066 MHz | 1.0–1.5 V | 40 W |
| SLAG6 | ||||||
| Xeon LV 5133 | SLABJ | 2.2 GHz | 4MB | 800 MHz | 1.0–1.5 V | 40 W |
| SLAG5 | ||||||
| Xeon LV 5138 | SL9RN | 2.13 GHz | 4MB | 1066 MHz | 1.0–1.5 V | 35 W |
| SLAG3 | ||||||
| Xeon LV 5148 | 2.33 GHz | 4MB | 1333 MHz | 1.0–1.5 V | 40 W | |
| SLABH | ||||||
| SLAG4 | ||||||
