Intel Xeon 5000/5100 Dual-Core CPUs

Intel Xeon 5000/5100 Dual-Core CPUs

Dell PowerEdge 1900 Intel Xeon 5000/5100 Processors

Intel Xeon 5000 Dual-Core ProcessorsReleased in mid to late 2006, the Intel Xeon dual-core 5000 and 5100 series processors (code named Dempsey and Woodcrest, respectively) are designed for high-performance dual-processor server and workstation applications. Based on the Intel NetBurst microarchitecture and Hyper-Threading Technology (HT Technology), they are scalable to two processors, providing exceptional performance for applications running on advanced operating systems such as Windows XP, Windows Server 2003, Windows Server 2008, Linux, and UNIX.

The dual-core Intel Xeon 5000 and 5100 series also include Hyper-Threading Technology (HT Technology) resulting in four logical processors per processor. This feature allows multi-threaded applications to execute more than one thread per physical processor core, increasing the throughput of applications and enabling improved scaling for server and workstation workloads.

The Dell PowerEdge 1900 will take up to two (2) processors. When adding a second processor to an existing server, the Intel sSpec code must match the first CPU.

Unless otherwise noted, processors have been tested and removed from working servers and are backed by our 90-day parts replacement warranty. Heatsinks are sold separately.

Click a processor below for more information, availability and pricing.

Intel Xeon 5000 Series Processors (Dempsey)
Model
number
Intel sSpec
number

Frequency

(GHz)

L2
cache

(per core)

Front Side Bus (FSB) Voltage TDP
Dual Core
Xeon 5020
  • SL96F
2.5 GHz 2 x 2MB 667 MHz 1.075–1.35 V 95 W
Xeon 5030 2.67 GHz 2 x 2MB 667 MHz 1.075–1.35 V 95 W
Xeon 5040
  • SL96D
2.83 GHz 2 x 2MB 667 MHz 1.075–1.35 V 95 W
Xeon 5050 3.0 GHz 2 x 2MB 667 MHz 1.075–1.35 V 95 W
Xeon 5060 3.2 GHz 2 x 2MB 1066 MHz 1.075–1.35 V 130 W
Xeon 5070
  • SL969
3.46 GHz 2 x 2MB 1066 MHz 1.075–1.35 V 130 W
Xeon 5080 3.73 GHz 2 x 2MB 1066 MHz 1.075–1.35 V 130 W
Dual Core, medium power
Xeon X5063 3.2 GHz 2 x 2MB 1066 MHz 1.075–1.35 V 95 W



Intel Xeon 5100 Series Processors (Woodcrest)
Model
number
Intel sSpec
number

Frequency

(GHz)

L2
cache



Front Side Bus (FSB) Voltage TDP
Dual Core
Xeon 5110 1.6 GHz 4MB 1066 MHz 1.0–1.5 V 65 W
SLABR
SLAGE
Xeon 5120 1.87 GHz 4MB 1066 MHz 1.0–1.5 V 65 W
SLABQ
SLAGD
Xeon 5130 2.0 GHz 4MB 1333 MHz 1.0–1.5 V 65 W
SLABP
SLAGC
Xeon 5140 2.33 GHz 4MB 1333 MHz 1.0–1.5 V 65 W
SLABN
SLAGB
Xeon 5150 2.67 GHz 4MB 1333 MHz 1.0–1.5 V 65 W
SLABM
SLAGA
Xeon 5160 3.0 GHz 4MB 1333 MHz 1.0–1.5 V 80 W
SLABS
SLAG9
Dual Core, low voltage
Xeon LV 5148 2.33 GHz 4MB 1333 MHz 1.0–1.5 V 40 W
SLABH
SLAG4
