Intel Xeon 5600 Westmere-EP CPUs

Intel Xeon 5600 Westmere-EP CPUs

Dell PowerEdge M710 Intel Xeon 5600 Series Processors (CPUs)


The Dell PowerEdge M710 server will accept up to two (2) Intel Xeon 5600 series processors.

Designed for industry-leading performance and maximum energy efficiency, the Intel Xeon processor 5600 sequence delivers versatile one-way and two-way 64-bit multi-core servers and workstations that are ideally suited for a wide range of infrastructure, cloud, high-density, and high-performance computing (HPC) applications.

The Intel Xeon processor 5600 series automatically regulates power consumption and intelligently adjusts server performance according to application demand, maximizing both energy cost savings and performance. Based on new 32nm Intel microarchitecture, the Intel Xeon processor 5600 series reduces energy cost over single-core servers by automatically shifting the CPU and memory into the lowest available power state, while intelligently adjusting performance to application needs.

In addition, built-in hardware-assisted virtualization technology gives you the power and flexibility to virtualize different generations of Intel Xeon processor-based servers within the same virtualization pool, giving you the ability to migrate workloads to fewer servers at night to save energy.

Selective processors in the Intel Xeon 5600 series also support Turbo Mode. Turbo Mode is an OS-controlled operation that automatically allows the processor to run faster than the marked frequency if the processor is operating below power, temperature, and current limits.

Unless otherwise noted, processors have been tested and removed from working servers and are backed by our 90-day parts replacement warranty. Heatsinks are sold separately.

Click a processor below for more information, availability and pricing.

Intel Xeon 5600 Series Processors (Westmere-EP)
Model
number		 Intel sSpec
number

Frequency

(GHz)

 Turbo Cores

L2
cache

(per core)

 L3
cache		 (QPI) TDP
Quad Core
Xeon E5603 1.6 GHz No 4 256 KB 4 MB 4.8 GT/s 80 W
Xeon E5606 2.13 GHz No 4 256 KB 8 MB 4.8 GT/s 80 W
Xeon E5607 2.27 GHz No 4 256 KB 8 MB 4.8 GT/s 80 W
Xeon E5620 2.4 GHz Yes 4 256 KB 12 MB 5.86 GT/s 80 W
Xeon E5630 2.53 GHz Yes 4 256 KB 12 MB 5.86 GT/s 80 W
Xeon E5640 2.67 GHz Yes 4 256 KB 12 MB 5.86 GT/s 80 W
Xeon X5647* 2.93 GHz Yes 4 256 KB 12 MB 5.86 GT/s 130 W
Xeon X5667 3.07 GHz Yes 4 256 KB 12 MB 6.4 GT/s 95 W
Xeon X5672 3.2 GHz Yes 4 256 KB 12 MB 6.4 GT/s 95 W
Xeon X5677* 3.47GHz Yes 4 256 KB 12 MB 6.4 GT/s 130 W
Xeon X5687* 3.6 GHz Yes 4 256 KB 12 MB 6.4 GT/s 130 W
Quad Core, low power
Xeon L5609 1.87 GHz No 4 256 KB 12 MB 4.8 GT/s 40 W
Xeon L5618 1.87 GHz Yes 4 256 KB 12 MB 5.86 GT/s 40 W
Xeon L5630 2.13 GHz Yes 4 256 KB 12 MB 5.86 GT/s 40 W
Six Core
Xeon E5645 2.4 GHz Yes 6 256 KB 12 MB 5.86 GT/s 80 W
Xeon E5649 2.53 GHz Yes 6 256 KB 12 MB 5.86 GT/s 80 W
Xeon X5650 SLBV3 2.67 GHz Yes 6 256 KB 12 MB 6.4 GT/s 95 W
Xeon X5660 SLBV6 2.8 GHz Yes 6 256 KB 12 MB 6.4 GT/s 95 W
Xeon X5670 SLBV7 2.93 GHz Yes 6 256 KB 12 MB 6.4 GT/s 95 W
Xeon X5675 SLBYL 3.07 GHz Yes 6 256 KB 12 MB 6.4 GT/s 95 W
Xeon X5680* SLBV5 3.33 GHz Yes 6 256 KB 12 MB 6.4 GT/s 130 W
Xeon X5690* SLBVX 3.47 GHz Yes 6 256 KB 12 MB 6.4 GT/s 130 W
Six Core, low power
Xeon L5638 SLBWY 2.0 GHz Yes 6 256 KB 12 MB 5.86 GT/s 60 W
Xeon L5639 SLBZJ 2.13 GHz Yes 6 256 KB 12 MB 5.86 GT/s 60 W
Xeon L5640 SLBV8 2.27 GHz Yes 6 256 KB 12 MB 5.86 GT/s 60 W
*130W CPUs require a Gen II system board.
See Dell's Intel Xeon 5600 Series Processors— Information Update
